How to Migrate Data from BigQuery to PostgreSQL

In today's data-driven world, the seamless movement of data between different storage solutions is paramount. Whether transitioning from a cloud-based data warehouse such as BigQuery to an on-premises database like PostgreSQL, a well-structured data migration strategy can save time, resources, and potential complications.

Data Migration

Prerequisites

Before delving into the details of our data migration process, ensure you have the following prerequisites:

A solid understanding of Python
Basic knowledge of databases
Python and pip installed on your system

To confirm that Python and pip are installed, run the following commands in your terminal:

python --version
pip --version

Setting Up the Environment

Let's begin by setting up the environment:

Create a new directory where you'll work on the migration script.
Inside this directory, manually create a file named requirements.txt. Alternatively, you can generate this file by running:

pip freeze > requirements.txt

Update requirements.txt with the following dependencies:

google-cloud-bigquery==3.10.0
numpy==1.25.2

You can adjust the version numbers according to your needs.

Authenticate the script by running:

gcloud auth login

This command will guide you through the authentication process, ensuring that the script can access your BigQuery data.

Want more database migration tutorials?

Creating the JSON Blueprint

Now, let's create a JSON file that acts as a blueprint for our migration script. This file will define the source BigQuery table, target PostgreSQL table, and column mappings.

[
  {
    "BigQueryTable": "AuthUsers",
    "PostgresTable": "Users",
    "unique_column": "id",
    "chunks": 100,
    "col": [
      {
        "source_column": "id",
        "destination_column": "id"
      },
      {
        "source_column": "firstname",
        "custom_hook": "first_name"
      },
      {
        "source_column": "lastname",
        "destination_column": "last_name"
      },
      {
        "source_column": "emailaddress",
        "destination_column": "email_address"
      },
      {
        "source_column": "password",
        "destination_column": "password"
      },
      {
        "source_column": "companyname",
        "destination_column": "company"
      }
    ]
  }
]

In this JSON structure, define the source and target table names, specify a unique column, set the number of chunks for data extraction, and map source columns to their destination columns as needed.

The Migration Script

Next, create a Python script named migration_script.py that will use the information from the JSON blueprint and BigQuery to generate SQL files for PostgreSQL import. Here's the script:

import os
import json
import numpy as np
import concurrent.futures
from google.cloud import bigquery

BIGQUERY_TABLE = "bigquery_table"
POSTGRES_TABLE = "postgres_table"
COLUMNS_STRUCTURE = "columns_structure"
UNIQUE_COLUMN = "unique_column"
PROJECT_ID = "your_project_id"
PROJECT_ID = "your_project_id"
CHUNKS = "no_of_chunks"

def read_json_data(json_file_path):
    """Read JSON migration data from a file."""
    with open(json_file_path) as f:
        return json.load(f)

def upsert(table, newdict):
    """Generate an upsert SQL query."""
    keys = list(newdict.keys())
    values = list(newdict.values())
    sql = [
        f"INSERT INTO {table} ({', '.join(keys)}) VALUES ({', '.join(values)});"
    ]
    return "".join(sql)

def divide_chunks(lst, n):
    """Divide a list into chunks of a specified size."""
    for i in range(0, len(lst), n):
        yield lst[i:i + n]

def process_chunk(chunk, source_table, destination_table, columns, project_id, unique_column):
    """Process a chunk of data and write SQL queries to files."""
    limit = np.subtract(chunk["end"], chunk["start"])
    offset = chunk["start"]
    client = bigquery.Client(project=project_id)
    query = f"SELECT DISTINCT * FROM your-bigquery-dataset.{source_table}" if unique_column else f"SELECT * FROM bmg-bigquery-test.prosaic.{source_table}"
    query_job = client.query(f"{query} LIMIT {limit} OFFSET {offset}")
    rows = query_job.result()

    output_folder = f"./sql_dump/{destination_table}"
    start_index = chunk["start"]
    end_index = chunk["end"]

    if not os.path.isdir(output_folder):
        os.makedirs(output_folder)

    sql_file_name = os.path.join(output_folder, f"{destination_table}_{start_index}_{end_index}.sql")

    with open(sql_file_name, "w") as file_sql:
        for _, row in enumerate(rows):
            data_dict = {}
            for col in columns:
                val = row[col["source_column"]]
                col_value = col.get("destination_column", col["source_column"])
                data_dict[col_value] = str(val)
            query = upsert(destination_table, data_dict)
            file_sql.write(f"{query}\n\n")

def main():
    json_file_path = input("Enter File Path: ")

    if not json_file_path:
        raise Exception("Oops! JSON migration file path required.")

    json_data = read_json_data(json_file_path)

    for data in json_data:
        source_table = data[BIGQUERY_TABLE]
        destination_table = data[POSTGRES_TABLE]
        unique_column = data.get(UNIQUE_COLUMN)
        columns = data[COLUMNS_STRUCTURE]
        no_of_chunks = data[CHUNKS]

        client = bigquery.Client(project=PROJECT_ID)
        query_params = f"DISTINCT {unique_column}" if unique_column else "*"
        query = f"SELECT COUNT({query_params}) as total_rows FROM your-bigquery-dataset.{source_table}"
        query_job = client.query(query)
        rows = query_job.result()
        total_rows = np.sum([int(row["total_rows"]) for row in rows])
        each_loop_records = int(total_rows / no_of_chunks)

        starts = np.arange(0, no_of_chunks * each_loop_records, each_loop_records)
        ends = np.append(starts[1:], total_rows)
        chunk_array = [{"start": start, "end": end} for start, end in zip(starts, ends)]

        with concurrent.futures.ThreadPoolExecutor(5) as executor:
            futures = [
                executor.submit(
                    process_chunk,
                    chunk,
                    source_table,
                    destination_table,
                    columns,
                    PROJECT_ID,
                    unique_column,
                )
                for chunk in chunk_array
            ]
            concurrent.futures.wait(futures)

        print("Migration Script Completed Successfully!")

if __name__ == "__main__":
    main()

Running the Migration

Execute the migration script by providing the path to the JSON blueprint file when prompted:

python migration_script.py

Sit back and watch as the script efficiently extracts data from BigQuery in chunks and generates SQL files for PostgreSQL.
Next, all that remains is to import those SQL files into PostgreSQL either manually or with the assistance of a script.

Conclusion

In conclusion, efficient data migration from BigQuery to PostgreSQL is crucial for businesses looking to make the most of their data. With a well-structured migration strategy, you can minimize downtime, maintain data integrity, and smoothly transition your data to its new home.

By following the steps outlined in this article and using the provided script, you'll be well-equipped to tackle data migrations effectively.
